How to choose a soldering station: types and features of equipment for soldering?

The rapid development of modern electronics, the reduction of mobile phone boards and other gadgets has moved the world towards lead Solder manufacturer. Soldering iron is no longer enough even for domestic use. To improve the quality and speed of soldering, both at home and in professional workshops, a more productive tool is required - a soldering station.

The choice of soldering station

The choice of a soldering station can raise many questions not only for a novice radio amateur, but also for an experienced service technician. What types of equipment are on the market? How to choose the right solution for specific task? We will discuss all in this article.

Soldering station type

Soldering stations are classified into several categories depending on the design and purpose. We will deal with each of these groups in detail.

Contact

Structurally, these are the simplest stations with minimal functionality. Generally speaking, this is a more powerful and improved soldering iron. Package Included:

• a soldering iron itself, sometimes with a set of stings;
• A control unit that provides the required temperature level. On it, different models differ mainly. For example, the indication on the block can be analog (with a scale), LED, digital (display);

Single-channel contact lead Solder manufacturer stations are compact and inexpensive devices. But their functionality is limited: such models are suitable only for the simplest operations.

Lead free soldering devices

Another type of contact soldering stations is lead-free soldering devices. This is a separate category of equipment, but they differ from the previous type, in fact, only in power. For soldering with lead-free solders, the temperature must be higher. This reflects in the cost of the equipment.

The rest of the functionality and equipment of the two named types of stations are similar. True, the design of stations for lead-free soldering can vary greatly for different models. The varieties described below can also be good for such tasks.

Hot air and combined lead Solder manufacturer stations

Hot air soldering stations designed primarily for the dismantling and assembly of small SMD components. Depending on the device of the hair dryer, they can be divided into two groups:

Compressor rooms

A compressor installs in the station block. When heated, it supplies air to the spiral through a hose. This rig makes the equipment heavy and bulky, but efficient. This type of station is best used to repair portable gadgets for lead Solder manufacturer.

Turbine

A turbine locates in the handle of the hair dryer, which supplies air to the spiral. In this type of hair dryer, the air flow is stronger than that of compressor ones. Therefore, they can be used for soldering not only electronic boards, but also plastics, as well as car bumpers.

Often, devices with a hairdryer and a soldering iron are called hot-air combined. These are the most versatile and demanded stations. In addition to the named components, the complete set may include a desoldering pump and other devices.

Lead Solder manufacturer dismantling method

As the name implies, this equipment is intended primarily for dismantling elements. Although there are models suitable for soldering, it all depends on the equipment and the principle of operation of the desoldering station.

There are two main options:

• the combined two-channel hot air devices described above;
• Single-channel stations with a desoldering gun that combines a soldering iron and a desoldering pump in one tool.

Also, infrared preheaters of boards are very popular among lead Solder manufacturer. With their help you can easily and efficiently dismantle without damaging the elements and the board. But the functionality of IR stations is wider. They cope not only with dismantling works.

Infrared heating stations

Infrared stations are by far considered the most suitable option for professional workshops that repair PCs and laptops. This type of device has been specifically designed to work with medium to large size, multi-part boards.

In fact, the IR station, with the possible exception of the most budgetary solutions, is a full-fledged complex for electronics repair. As a rule, they are equipped with:

• a high power top heater directly for unsoldering contacts;
• a large bottom heater (preheater) - it prevents deformation of the textolite base, making heating even;
• a table for fixing equipment;
• Automatic temperature control system. It includes temperature sensors and a controller and automatically monitors the operating temperature range and exposure time according to the specified criteria.

How does lead Solder manufacturer help in making semiconductor?

Such equipment allows lead Solder manufacturer to work effectively with large boards. For example - "motherboards" of stationary and laptop computers in a semi-automatic mode. The operator just needs to fix the part and set the required thermal profile.

The impact on plastic parts is also minimized. In addition, with such equipment, there is no need for attachments for each specific microcircuit. Given the modern variety of boards, this will significantly save your budget and further simplify the process itself.

Additional equipment for soldering stations

The station performs the main functions, regardless of the configuration and equipment. However, additional options will make your workflow more comfortable. For example, many models can be equipped with:

Outcome

Soldering station - equipment designed for tasks in which the functionality of a conventional soldering iron is not enough. These are more powerful and more advanced devices in design and equipment.

Depending on the goals of the operator, different types of stations should be used. For example, for domestic use, contact and combined hot air are most popular. In professional SCs, infrared devices are most in demand.

More than once, many have come across a situation when their favorite headphones stop working. What can you do, not a rare occurrence. You can, of course, buy new ones, but re-soldering the wire on the old ones is much cheaper.

The impact of immature lead soldering

And most importantly, there is nothing difficult for lead Solder manufacturer. Below I want to give a couple of elementary ways. It can come in handy in life and save some money. This, in turn, can be spent on ice cream, going to the cinema with a girl, or any other business.

The tip is one of the basic elements in the design of any soldering device. Even a simple amateur soldering iron often has a tip change mechanism. It is extremely rare today to find models without a replacement mechanism.

The reasons for this technical approach are understandable. Firstly, any sting wears out sooner or later, which means it needs to be replaced. The tip is primarily talks about the thickness, shape and material of the tip.

WHAT TYPES OF TIPS ARE ON THE MARKET?

The material, shape, coating and thickness of the tip determine the degree of power dissipation. And some other characteristics that are important for choosing an adequate device for the operating conditions.

At the same time, lead Solder manufacturer emphasize the role of the material and shape of the tip. Earlier, we partly touched on this issue without going into its details. Therefore, it makes sense to eliminate this deficiency.
